Name: Sparkforensics
Author: shuffle-works

Your Spark job is slow. SparkForensics tells you why, and what to do about it.

Drop a Spark event log in and get an evidence-backed breakdown of which stages are slow, why, and how to fix them. Nothing installs on your cluster and nothing leaves your machine.

Try it now → with your own event log. No install, no account, no upload. Read the documentation for a guided tour.

Spark's own History Server gives you raw metrics. It won't tell you that stage 14 spilled 40GB because of a skewed join key, or that cold start is eating a third of the job. SparkForensics reads the same event logs and turns them into findings.

Why SparkForensics

Your data stays on your machine. Drop a log file and read the dashboard; nothing is uploaded anywhere. Local-server mode adds a small Node companion that can also pull runs from a Spark History Server.
Event logs are streamed and parsed off the main thread in a Web Worker, so a 240MB+ (or multi-GB) NDJSON log doesn't freeze the tab.
About 25 built-in detectors cover skew, shuffle, spill, GC pressure, stragglers, cold start, cache/memory utilization, autoscaling churn, job/stage failures and partition sizing, plus a SQL Plan Advisor (duplicate subtrees, small files, broadcast sizing) and a config audit. Full roster in the detector contract.
Fix These First orders every finding by its estimated wall-clock impact, not severity alone, so the top row is the fix worth doing first.
Run comparison (A/B) mode structurally matches stages across two runs of the same job and shows which stages regressed, rather than every difference.
Every finding tracks what it could and couldn't confirm from the log, so you know when to trust a flag and when it's a hint worth checking manually.
A headless CLI (sparkforensics-analyze) evaluates a run against budget thresholds (max runtime, skew, spill, failure rate...) and exits non-zero on violation, so a regression can fail a build. The run can come from a local event-log file/directory or, with --shs-base-url, fetched directly from a Spark History Server.
An MCP server (sparkforensics-mcp) exposes tools for diagnosing, summarizing and comparing runs, so an LLM agent can investigate a run directly. The full tool list is in MCP tools.
For running the analyze CLI automatically after every Spark job instead of by hand, see sparkforensics-operator, an Airflow operator that runs SparkForensics on a job's event log and acts on the result.

Unlike tools that need a cluster-side plugin or a running server plus an LLM agent (Spark History Server MCP tools), SparkForensics needs nothing installed anywhere else: the event log and a browser tab are enough.

Get started

Run the dashboard locally:

bash

npx sparkforensics-server

The Getting started guide covers what it serves, the live demo alternative, and loading a run. To work on SparkForensics itself, see Development.

For a one-shot check with no browser, the kind a CI pipeline can gate on:

bash

npx -p sparkforensics-cli sparkforensics-analyze path/to/eventlog --max-runtime 3600000 --max-skew 3

The command ships in the sparkforensics-cli package. To install it once instead: npm i -g sparkforensics-cli, then run sparkforensics-analyze directly. The sparkforensics-analyze alias package also works: npx sparkforensics-analyze.

That's a headless run against budget thresholds. See Command-line reference below for HTML export, Spark History Server fetching, baseline comparisons, and redaction.

Development

Install and run

From a checkout:

bash

git clone git@github.com:shuffle-works/sparkforensics.git
cd sparkforensics
npm install
npm run dev

Open the URL Vite prints. For a production bundle: npm run build, then serve dist/ with any static file server. Asset URLs are relative, so the bundle also works under a URL subpath.

Note: The app must be served over HTTP: file:// URLs block Web Worker module imports in Chrome.

Deploy modes

This app runs in two modes:

Static mode (e.g. GitHub Pages, or any plain file server): Choose file is the normal browser-local path for a single event log. Choose rolling-log folder is available only for an eventlog_v2_* directory. Deploy the output of npm run build from dist/. Fetching directly from a Spark History Server is not available: the browser's CORS policy blocks it and a static host can't proxy the request. If a History Server load cannot be used, choose a local event-log file instead.
Local-server mode is a small Node companion that serves this app and fetches from a Spark History Server on your behalf (server-to-server, so no browser CORS restriction). Useful when the SHS is behind a VPN or isn't CORS-configured.

Run local-server mode with:

bash

npx sparkforensics-server

It listens on http://127.0.0.1:4173 by default (override with --port or the PORT env var) and binds to localhost only. Open the URL in Chrome and use the Fetch from Spark History Server disclosure on the intake screen. The same server serves the MCP tools over streamable HTTP at /mcp, for clients on the same machine; see Connecting over HTTP.

History Server fetching requires local-server mode, a History Server reachable from the machine running that server, and a supported base application ID (see Getting started for the full list of accepted forms). Enter an optional attempt separately from the base application ID. The local server sends no credentials and follows no upstream redirects. Its recoverable errors intentionally omit upstream response details; edit the fields or choose a local event-log file to recover.

During development from a checkout, npm run local-server does the same thing without publishing or installing the package.

Server configuration

All settings have working defaults; override them with environment variables:

Variable	Default	Effect
`PORT`	`4173`	Listen port (the `--port` flag takes precedence)
`SPARKFORENSICS_SHS_TIMEOUT_MS`	`30000`	Spark History Server fetch timeout: response headers must arrive within this window, and a streaming body that goes idle this long is cut off. Applies to both the `/shs-proxy` route and the MCP archive download. Progressing downloads of any size are unaffected.
`SPARKFORENSICS_MCP_CACHE_CAP`	`8`	Max parsed runs kept in the MCP tool cache
`SPARKFORENSICS_MCP_CACHE_TTL_MS`	`900000`	Idle eviction time for cached MCP runs (15 min)
`SPARKFORENSICS_MAX_ARCHIVE_BYTES`	`1073741824`	Largest SHS event-log archive the MCP tools or the `--shs-base-url` CLI mode will buffer (1 GiB); larger responses fail with `archive-too-large`

SHS-proxy route test fixture

The /shs-proxy route (packages/core/src/proxy.js) is covered by packages/server/test/shs-proxy-fixture.test.js, part of the normal npm run test:server suite. It loads a real event log from the spark-event-corpus-data git submodule at dev/log-corpus/ and asserts the route streams it back as a valid ZIP. No Docker, no live Spark process, and no live History Server are needed for this.

To verify the full Fetch-from-SHS UI flow by hand, including its unreachable-upstream and application-not-found recovery states, point npm run local-server at a real Spark History Server you have access to and use its Fetch from Spark History Server disclosure. Automated coverage of /shs-proxy uses the spark-event-corpus-data logs, so no Docker image or live Spark process is needed.

Running tests

bash

npm test              # single run
npm run test:watch    # watch mode
npm test -- tests/finding-filter.test.js  # single file
npm run test:core     # packages/core: detectors, analyzer, parser, MCP tools
npm run test:cli      # packages/cli
npm run test:mcp      # packages/mcp
npm run test:server   # packages/server

Command-line reference

Beyond the plain budget check in Get started, the same sparkforensics-analyze CLI covers a few other jobs.

Write a self-contained HTML dashboard for the run instead of a JSON/Markdown report, viewable offline over file:// with no server:

bash

npx -p sparkforensics-cli sparkforensics-analyze path/to/eventlog --export-html path/to/output-dir

Fetch the run straight from a Spark History Server instead of a local file (mutually exclusive with the positional path):

bash

npx -p sparkforensics-cli sparkforensics-analyze --shs-base-url http://history-server:18080 --app-id application_1234_0001 --max-skew 3

Compare a candidate run against a baseline (A/B) and fail the build on a regression or a newly introduced critical finding:

bash

npx -p sparkforensics-cli sparkforensics-analyze path/to/candidate --baseline path/to/baseline --max-regression-pct 10 --fail-on-introduced critical

Several regression budgets in one call, and several candidates against one baseline (NDJSON, one line per candidate; the baseline is parsed once):

bash

npx -p sparkforensics-cli sparkforensics-analyze cand-1 cand-2 cand-3 --baseline base --regression-budget wallClock:10 --regression-budget gcTime:25

See Several budgets and several candidates for the --budgets file, the NDJSON line fields and the exit code rules.

Redact the app id, the app name and any host/IP tokens before sharing the output outside the environment that produced it:

bash

npx -p sparkforensics-cli sparkforensics-analyze path/to/eventlog --redact

Narrow the output's findings array to certain impact bands, types, or a stage (recommendations/cleanChecks/notRunChecks and the summary counts stay on the full, unfiltered set):

bash

npx -p sparkforensics-cli sparkforensics-analyze path/to/eventlog --impact critical,warning --type stageSlowness --stage 12

Other budget flags round out the checks: --max-spill <gb>, --max-failed-task-rate <pct>, and --min-efficiency <pct> (busy core time: the share of executor core time that ran tasks, 100 minus the dashboard's Unused core time, not its Efficiency tile). --attempt-id pairs with --shs-base-url/--app-id for a non-default attempt; --regression-metric picks which metric --max-regression-pct checks (default wallClock); --conf-keys and --conf-redact-regex shape the JSON output's effectiveConf block, next to its metrics block (both in Getting started); --format md switches output to Markdown (default json); --out <path> writes it to a file instead of stdout. Exit codes: 0 pass, 1 a budget was violated, 2 usage error (bad flags, arguments or a --thresholds/--budgets file), 3 a budget was inconclusive (e.g. missing evidence for a regression check), 4 the candidate log can't be read or parsed, 5 the baseline log can't be read or parsed, 6 internal error. When several apply, the worst wins in the order 6, 5, 4, 1, 3, 0; with several candidates that means the worst line, and a candidate that can't be read or parsed gives its own line 4.

Node version: the published sparkforensics-cli, sparkforensics-mcp, and sparkforensics-server packages all pre-strip their vendored TypeScript to plain JS at publish time, so npx-installed use only needs Node >=18 (see each package's engines field). A checkout running any of the three straight off packages/*/bin/ against packages/core/src/*.ts (the monorepo dev-mode fallback) needs a Node version with native (unflagged) TypeScript type-stripping instead: >=22.18.0 on the Node 22 LTS line, or >=23.6.0 on Node 23+.
